Please note: This is a Direct Delivery Product
Specifications
Speed 10 cases per minute 8 cases per minute
Minimum Case Outer Dimensions
200 mm L x 150 mm W x 150 mm C
(7 7/8” L x 5 7/8” W x 5 7/8” C)
200 mm L x 150 mm W x 250 mm C
(7 7/8” L x 5 7/8” W x 9 7/8” C)
Maximum Case Outer Dimensions
500 mm L x 350 mm W x 600 mm C
(19 5/8” L x 13 3/4” W x 23 5/8” C)
620 mm L x 450 mm W x 650 mm C
(24 3/8” L x 17 3/4” W x 25 5/8” C)
Case Type RSC, HSC, FEFCO 0200/0201 RSC, HSC, FEFCO 0200/0201
Flute Type B, C B, C
Wall Type Single Wall Single Wall
Standard Sealing Device Lantech® TH-Series Tape Head Lantech® TH-Series Tape Head
Dimensions - Machine
6050 mm L x 2430 mm W x 1600 mm H
(238 5/16” L x 95 3/4” W x 63” H) *Profi tPack 300 Double StaƟ on
7050 mm L x 2430 mm W x 1600 mm H
(277 11/16” L x 95 3/4” W x 63” H)
6200 mm L x 2540 mm W x 1600 mm H
(244 3/16” L x 100 1/8” W x 63” H)
*Profi tPack 400 Double StaƟ on 7200 mm L x 2540 mm W x 2500 mm H
(283 5/8” L x 100 1/8” W x 63” H)
Weight - Machine ±950 kg (±1155lb) ±1000 kg (±1265lb)
Electrical Service Choices 3L-PE-400V-50Hz-Neutral
230V, 3-ph, 60Hz, Wye w/Ground
3L-PE-400V-50Hz-Neutral
230V, 3-ph, 60Hz, Wye w/Ground
PneumaƟ cs 6 Bar (80 PSI) 6 Bar (80 PSI)
